echnical properties
Architecture
- Neutral positionright
- Number of poles4 P
Functions
- Concurrently switching N-neutralYes
Configuration
- Number of modules4
Main electrical features
- Rated operational voltage Ue230 / 400 V
- Frequency50 Hz
Voltage
- Rated insulation voltage500 V
- Rated impulse withstand voltage4000 V
Electric current
- Rated residual operating current30 mA
- Rated current25 A
- Withstand not tripping on 8-20 μs wave0.25 kA
- Breaking and opening capacity1.5 kA
- Rated conditional short-circuit current Inc according to EN 61008-16 kA
Electric current / temperature
- Rating current -25°C25 A
- Rating current -20°C25 A
- Rating current -15°C25 A
- Rating current -10°C25 A
- Rating current -5°C25 A
- Rating current 0°C25 A
- Rating current 5°C25 A
- Rating current 10°C25 A
- Rating current 15°C25 A
- Rating current 20°C25 A
- Rating current 25°C25 A
- Rating current 30°C25 A
- Rating current 35°C25 A
- Rating current 40°C25 A
- Rating current 45°C25 A
- Rating current 50°C25 A
- Rating current 55°C25 A
- Rating current 60°C25 A
- Rating current 65°C22 A
- Rating current 70°C18 A
Dimensions
- Depth of installed product70 mm
- Height of installed product83 mm
- Width of installed product70 mm
- Construction size (DIN 43880)1
Frequency
- Frequency50 Hz
Power
- Total power loss under IN4.5 W
- Power loss per pole at In2 W
Tripping
- Protected against nuisance trippingNo
- Short-time delayed trippingNo
Endurance
- Electric endurance in number of cycles2000
- Number of mechanical operations4000
Installation, mounting
- Type of top connection for modular deviceswith screw
- Tightening torque2,8Nm
- Type of top rail clip for modular devicesNA
- Type of bottom rail clip for modular devicesmetallic
- Type of Bottom Connection for modular devicesBIconnect
- Top removability for modular devicesNo
- Bottom removability for modular devicesNo
Connection
- Connection cross-section at output with screw, for massive conductor1 / 25 mm²
- Connection cross-sect. flexible conductor16mm²
- Connection cross-sect. rigid cable25mm²
- Connection cross-section for rigid conductor, upstream terminals with screws1 / 25 mm²
- Connection cross-section of the access with screws, with flexible conductor1 / 16 mm²
- Connection cross section of access and exit with screws, for flexible conductor1 / 16 mm²
- Type of connectionwith screw
Standards
- Standard textIEC 61008-1 ; EN 61008-1
- European directive WEEEconcerned
Safety
- Residual current typeAC
- REACH conformNo
- RoHS conformYes
- Halogen freeNo
Use conditions
- Operating temperature-25…40 °C
- Degree of pollution according to IEC 60664 / IEC 60947-22
- Altitude2000 m
- Storage/transport temperature-55…70 °C
